Extraction Arm | KUA-200
  • Extraction Arm | KUA-200
Extraction Arm | KUA-200

Extraction Arm | KUA-200

KUA-200 is a heavy-duty aluminum tube extraction arm with an 8 inch (200 mm) diameter, designed to capture large volumes of welding fumes, gases, and oil mist directly at the source. Engineered for medium and large workplaces with intensive fume generation.

Features:

  • Large 8 inch (200 mm) diameter for maximum airflow capacity
  • External middle hinge for tool-free adjustments
  • Spring-assisted joints with double ball bearings for smooth movement
  • Universal mounting bracket with 360° rotation
  • Large hood with 340 mm (13.4 in) opening, movable up to 85° in four directions
  • Removable hood with safety mesh for user protection and easy maintenance
  • Sealed shut-off and control valve for reliable operation
  • Smooth aluminum tubing for maximum airflow and reduced noise
$2,392.00 USD

Heavy-duty aluminum tube extraction arm. Recommended for:
  • Heavy-duty welding fume extraction
  • Medium to large welding shops and fabrication facilities
  • Industrial environments with intensive fume generation
  • Workplaces requiring high airflow capacity
  • Plant maintenance with frequent welding activity
  • Combination with high-capacity fans and stationary filter units
  • General fabrication and production environments
Kenmerkenen & highlights

Smooth aluminum inner and outer tubing for maximum airflow

  • External elbow joint and spring-assisted middle joint for one-movement positioning
  • Universal mounting bracket with ball-bearing and friction pad for 360° rotation
  • 360° ring handle for easy access from any position
  • Lightweight construction reduces noise and operator fatigue
  • Stays in position once placed, no drift
Documents & Specs

Extraction Arms Brochure EN

Product Brochure (En)

Product Data Sheet (En)
Recommended use:

Suitable for:

✓ MIG/MAG welding fume extraction (heavy-duty applications)
✓ TIG welding fume extraction
✓ Stick / MMAW welding fume extraction
✓ FCAW welding fume extraction
✓ Fume extraction during grinding
✓ Fume extraction during polishing
✓ Fume extraction during finishing
✓ Oil mist and solvent fume extraction
✓ Combination with FUA fans, WallPro, and other high-capacity stationary systems
✓ Standing (wall or filter unit mounted) or hanging (ceiling mounted) configurations
✓ Industrial environments with high fume volumes

Not suitable for:

✗ Use in explosive environments (use the KUA-200 ATEX version instead)
✗ Extraction during aluminum laser cutting
✗ Extraction during grinding of aluminum or magnesium
✗ Extraction of aggressive fumes and gases (e.g., acids, alkaline substances, lithium-containing soldering pastes)
✗ Extraction of hot gases (continuously above 158°F / 70°C)
✗ Extraction during flame spraying
✗ Extraction of cement, sawdust, wood chips, etc.
✗ Vacuuming cigarettes, cigars, oiled tissues, or other glowing, flammable, or burning materials, objects, or acids
✗ Light-duty or compact workspace applications (consider KUA-160 instead)
Product specifications
Category Specification Details
Physical dimensions and properties Material (tubing) Smooth aluminum inner and outer tubes
Diameter Ø 200 mm (8 in.)
Hood opening Ø 340 mm (13.4 in.)
Hood movement Up to 85° in four directions
Available lengths 3 m (10') or 4 m (13')
Maximum reach Up to 4 m (13 ft)
Rotation 360° at mounting bracket and hood
Performance Recommended airflow 1500 to 1800 m³/h (880 to 1060 CFM)
Capture efficiency Up to 95% within capture zone
Operating temperature Up to 70°C (158°F) continuously
Construction Joint type External middle hinge, spring-assisted joints
Bearings Double ball-bearing supported
Mounting bracket Universal, with ball-bearing and friction pad
Handle 360° ring handle at hood
Valve Sealed shut-off and control valve
Compatible units Stationary filter units WallPro, SCS, MDB
Fans FUA (high-capacity extraction systems)
Configuration Standing or hanging
Available extensions FlexMax extension crane Adds 1.5, 2.5, 3.5, or 4.5 m (max reach 8.5 m / 28 ft)
NEC extension crane Wall-mounted crane to extend reach across multiple work areas
Shipping data Weight (net) 19 kg (42 lbs)
Packing dimensions 174 × 36 × 66 cm (68.5 × 14 × 26 in.)

Product description

The KUA-200 is the heavy-duty member of the KUA extraction arm family, engineered for medium and large workplaces where welding activity generates high volumes of fumes, gases, and oil mist. With an 8 inch (200 mm) tube diameter, the KUA-200 delivers significantly more airflow than the KUA-160, making it the right choice for industrial environments with intensive fume production and demanding extraction requirements.

What sets the KUA-200 apart is the combination of smooth aluminum inner and outer tubing, an external middle hinge that adjusts without tools, and spring-assisted joints supported by double ball bearings. This construction means the arm moves precisely with one hand, holds its position once placed, and reduces operator fatigue throughout long working shifts. The aluminum tubing keeps the arm relatively lightweight despite the larger diameter, while maximizing airflow and minimizing noise.

The hood is one of the most distinctive features of the KUA-200. With a 340 mm (13.4 in.) opening, movable up to 85° in four directions, the hood positions exactly where capture is needed. The 360° ring handle gives operators full control from any angle, while the removable hood with safety mesh protects the operator and simplifies maintenance. A sealed shut-off and control valve ensures reliable airflow regulation.

The KUA-200 pairs with high-capacity Plymovent filter units and fans, including the FUA, WallPro, SCS, and MDB systems. For workspaces requiring extended reach, combine the arm with the FlexMax extension crane (up to 8.5 m / 28 ft total reach) or the wall-mounted NEC extension crane to cover large or multiple work areas.

Reliable, high-quality solution for heavy-duty source extraction

The KUA-200 is the right choice when welders and fabricators need an extraction arm that handles serious fume volumes without compromise. Its larger diameter, robust construction, and large capture hood deliver the airflow and reach needed for industrial applications, while the smooth movement and stable positioning make it comfortable to use throughout demanding production shifts.

You will typically find the KUA-200 in larger welding shops, heavy fabrication facilities, automotive manufacturing, structural steel production, and industrial environments where source capture is essential to protect personnel from hazardous airborne contaminants. It offers an effective, ergonomic solution for workspaces where the lighter-duty KUA-160 simply cannot keep up with the volume of fumes generated.
